Forklift trucks MI-X 18 D
Request a Quote Download BrochureKey Information
Load center of gravity
500 mm
Wheelbase
1 420 mm
Load distance, centre of drive axle to fork
405 mm
Contact Our Experts
Morocco
International
Monday to Friday 8am-5:30pm (UTC)
Product Specifications for MI-X 18 D
- TECHNICAL CHARACTERISTICS
- Model NameMI-X 18 D
- Power sourceDiesel
- Operator typeSeated
- Load center of gravity500 mm
- Wheelbase1 420 mm
- Load distance, centre of drive axle to fork405 mm
- Max. capacity1 800 kg
- WEIGHT
- Service weight3 100 kg
- Weight on front axle (laden)4 260 kg
- Weight on front axle (Unladen)1 315 kg
- Weight on rear axle (laden)640 kg
- Weight on rear axle (Unladen)1 785 kg
- WEIGHT AND DIMENSIONS
- Height of overhead guard (cabin)2 090 mm
- Seat height/stand height1 160 mm
- Height of towing bar (coupling height)315 mm
- Overall length3 350 mm
- Length to face of forks2 280 mm
- Overall width1 080 mm
- Overall width - Single wheels1 080 mm
- Forks section35 mm
- Forks width100 mm
- Forks length1 150 mm
- Fork carriage ISO 2328 (class/form) A/B2A
- Fork carriage width1 000 mm
- Ground clearance below mast115 mm
- Ground clearance at centre of wheelbase150 mm
- Aisle Width for pallets 1000 x 1200 crossways3 615 mm
- Aisle width for 800 x 1200 pallet lengthways3 815 mm
- Turning radius2 010 mm
- Internal turning radius (over tyres)55 mm
- WHEELS
- Tires typeSolid tires
- Dimensions of front wheels6.50-10 10
- Dimensions of rear wheels5.00-8 8
- Number of front wheels2
- Number of rear wheels2
- Front wheel gauge900 mm
- Rear wheel gauge920 mm
- MASTS
- Max. lifting height6 500 mm
- PERFORMANCES
- Travel speed (laden)18,6 km/h
- Travel speed (unladen)19,3 km/h
- Lifting speed (laden)0,5 m/s
- Lifting speed (unladen)0,55 m/s
- Lowering speed (laden)0,5 m/s
- Lowering speed (unladen)0,55 m/s
- Gradeability (laden)20 %
- Gradeability (unladen)20 %
- Service brakeHydraulic
- ENGINE
- Engine brandYanmar
- Engine model4TNE92-HRJ
- Engine normStage IIIA
- Engine power (Hp)45 Hp
- Engine power (kW)32,8 kW
- Rated speed2 450 rpm
- Capacity of cylinders2 659 cm³
- Number of cylinders4
- TRANSMISSION
- Transmission typeTorque converter
- Drawbar pull (Laden)1 440 daN
- Drawbar pull (Unladen)795 daN
- HYDRAULICS
- Oil flow rate for attachments56 l/min
- Working hydraulic pressure for attachments160 bar
- NOISE AND VIBRATION
- Sound level at the driver's ear according to DIN 12 05386 dB
- Measured/guaranteed mean noise level at the ear of the operator86 dB
