Asphalt pavers AP300
Request a QuoteKey Information
Standard Laying Range
1.75 m - 3.42 m
Maximum flow
8,200 kg
Maximum flow
406 t/h
Overview
Simple and Smooth
The AP300 Paver is a small to medium-sized model that offers a paving range from 1.75m to 4.0m (5.6 ft to 11.1 ft), making it an ideal solution for urban roads, bike paths, pedestrian streets, emergency lanes, and other small to medium-sized projects. An optional reduction can decrease the paving width to 700mm (27") for trenching work and other narrow applications. Advanced technological features such as Eco mode, automatic filling, one-touch power activation, and automated travel mode make the combination of this paver and screed extremely productive and versatile for small and large general contractors.
Advantages
Advanced Technology
The advanced Eco mode reduces fuel consumption while the one-touch material feeding functions improve efficiency.
User-Friendly
Good panoramic visibility combined with comfort and interactive displays to help operators achieve high performance.
Flexible Paving Range
The wide paving range and narrow reduction kit provide exceptional versatility for urban roads and trenching work.
Key Features
- Results of very high quality, higher revenues
- A Technology That Adapts To Your Activity
- Low operating costs
- Unmatched after-sales support
- More Comfort
- Tables That Offer Great Quality
- Product Link™ Elite
- Maintenance and repair kits
Results of very high quality, higher revenues
Standard laying range from 1.75m to 3.2m (5' 9" to 11' 2") with a maximum width of 4m (13' 1") providing excellent performance for parking areas, urban roads, driveways, trenches, narrow shoulders, and other medium-sized applications. An optional laying reduction equipment allows reducing the laying width up to 700mm (27.5"). Heated end gates, variable frequency vibration, and tamper bar adjustments allow for a smooth material flow. """
A Technology That Adapts To Your Activity
The exclusive Eco mode, as well as the automatic engine speed control, reduce fuel consumption and decrease noise levels, for better comfort and smoother communication. The automatic filling power system simplifies setup by filling the feed screw chamber up to the set point determined by the feed sensors. Activating the power device with a simple press optimizes efficiency by activating each feed screw and conveyor. Automated translation function; the feed screws rise with the table, avoiding damage during transport. The hopper control with a simple press allows the driver to focus on other tasks.
Low operating costs
Availability of engine options compliant with Tier 4 Final EPA emissions standards for the United States, Stage V for the European Union, and other regional standards. Contactors guaranteeing one million cycles offer high reliability. Conveyor base plates and chain casings are designed to minimize repairs and offer low-cost replacement. Heating elements slide for easy replacement. Machined table frames facilitate leveling of the smoothing plate.
Unmatched after-sales support
Strategically located dealerships offering 24/7 support Machine maintenance training for technicians Training for paver operators to optimize machine performance Project consulting to improve techniques and facilitate site management
More Comfort
The ventilation system option sucks the fumes from the feed screw chamber away from the operator. This allows the operator to have a more comfortable working environment. The unique sliding console allows for use on both sides of the machine. The two independent seats can rotate beyond the platform for good visibility of edges and obstacles. The heated seat option provides great comfort during cool weather conditions. The high visibility 76 mm (3") seat belt allows for the implementation of compliant safety measures for the team. """
Tables That Offer Great Quality
The SE34 V and SE34 VT tables offer great driving comfort, high mass density, and excellent coating texture, while providing superior adjustment features. Basic leveling control option available.
Product Link™ Elite
Make optimal decisions at the right time, based on facts to increase productivity while reducing operating costs. Easily access real-time location, operating hours, fuel consumption, and downtime. Diagnostic codes are available online through web applications. Scheduled maintenance notifications and periodic oil sampling.
Maintenance and repair kits
Standard laying range from 1.75m to 3.2m (5' 9" to 11' 2") with a maximum width of 4m (13' 1") providing excellent performance for parking areas, urban roads, driveways, trenches, narrow shoulders, and other medium-sized applications. An optional laying reduction equipment allows reducing the laying width up to 700mm (27.5"). Heated end gates, variable frequency vibration, and tamper bar adjustments allow for a smooth material flow. """
Contact Our Experts
Morocco
International
Monday to Friday 8am-5:30pm (UTC)
Product Specifications for AP300
- OPERATING CHARACTERISTICS
- Standard Paving Range1.75 - 3.42 m (5.6' - 11.1')
- Maximum Throughput406 tonnes/hr
- Maximum Travel Speed16 km/h
- Maximum Paving Speed61 m/min
- Maximum Paving Width4 m
- Minimum Paving Width700 mm
- ENGINE
- Engine Model (1)C3.3B Cat
- Engine Power (1)55 kW
- WEIGHT
- Operating Weight: with SE34 VT8200 kg
- Operating Weight: with SE34 V8000 kg
- Shipping Weight, Paver Only6600 kg
- DIMENSIONS
- Wheelbase1950 mm
- Length in Operating Position5047 mm
- Width in Operating Position3180 mm
- Operating Height, with Roof3415 mm
- Transport Height2645 mm
- Transport Width1938 mm
- Transport Length5029 mm
- MAINTENANCE CAPACITIES
- Fuel Tank110 l
- Coolant System (1)9 l
- Engine Oil (1)13.2 l
- Washdown Spray Tank28 l
Standard Equipment for AP300
-
DRIVER'S COMPARTMENT
- Single Sliding Console
- Directional Guide
-
TECHNOLOGY
- Product Link™ Elite 6412 (Cellular)
-
POWERTRAIN
- C3.3B CAT®, Four-Cylinder
- Variable-Speed Cooling Fan
- Radial Tires
-
ELECTRICAL CIRCUIT
- Maintenance-Free 750 CCA Battery
- 85A Alternator
- 12V Power Supply Circuit
- Automotive-Type Fuse System
- ET CAT® Electronic Device
-
MATERIAL DELIVERY
- Contact Material Feed Sensors
- Adjustable Push Roller
-
MAINTENANCE AND SERVICE
- Hydraulic Oil, Cat HYDO™ Advanced
- Remote Access to Drain Points
- Maintenance and Repair Kits
- Periodic Oil Sample Tap Points
- Coolant and Hydraulic Oil Level Gauges
-
SAFETY
- Reverse Warning
- Horn, Alarm (Front and Rear)
- LED Lights
- Mirror Kit
Available Options for AP300
-
DRIVER'S COMPARTMENT
- Roof
- Deceleration Pedal
- Sunshade/Umbrella
- Ventilation System
-
TECHNOLOGY
- Basic Leveling Control
- Product Link™ 631 Satellite
-
POWERTRAIN
- Front Weight Ballast
- Front Wheel Assist
-
MATERIAL DELIVERY
- Ultrasonic Material Feed Sensors
- Wash Pump and Reel
-
MAINTENANCE AND SERVICE
- Biodegradable Hydraulic Oil
