Track loaders 963K
Request a QuoteKey Information
Flywheel Power
144 kW
Operating weight
20,021 kg
Capacity - Normal GP
2.5 m³
Overview
One Machine, Multiple Tasks
Save money and reduce transportation time with a machine for clearing, excavation, leveling, dump truck loading, slope work, and more. Track loaders offer reduced ground pressure and improved traction so you can start work earlier and work longer on soft soils. CAT® track loaders offer all of this, combined with superior performance and fuel efficiency.
AdvantagesVersatile
The most versatile machine on the job site allows you to clean, dig, level, load, transport, and much more, all with one machine. Special configurations allow you to work in landfills and ship holds.
Up to 25% Fuel Savings
Eco modes and a more efficient engine allow you to perform a wide variety of tasks while consuming much less fuel.
Reduced Ground Pressure
Work when and where other machines cannot. Track loaders provide you with traction and flotation on different terrains, allowing you to work where other machines stay away.
Key Features
- More Tasks With Less Fuel
- Designed to be Performant
- Develop Your Skills
- Ease of use
- Reduced Maintenance Time
- Keep Things in Order
More Tasks With Less Fuel
The 963K model consumes 10 to 25% less fuel per hour than the previous model. The efficient use of diesel exhaust fluid, which generally represents 2.5 to 3% of fuel consumption, offers excellent overall fluid efficiency. The optional high-performance bucket allows you to move up to 5% more material per hour. The variable speed fan provides efficient cooling, and the foldable panel makes maintenance access easier. Remote monitoring through Product Link™/VisionLink® software helps you manage your fleet more efficiently and cost-effectively. * Machine equipped with emission reduction technology compliant with US EPA Tier 4 Final/European Stage IV standards.
Designed to be Performant
The response of the equipment and the steering is more flexible and the steering is more efficient than on the old model. Features such as load sensing hydraulic circuit and position sensing cylinders provide precise and immediate performance. The C7.1Cat engine offers power and quick response when the machine is under load. Engine noise reduction: quieter for the operator and other people present on the construction site.
Develop Your Skills
The steel track undercarriage allows you to work on wet, soft, or sensitive terrain. Complete your tasks more quickly: track loaders are often able to start tasks earlier and work longer than other machines, due to their lower ground pressure and better traction. Quick coupler pre-equipment: the optional Fusion™ quick coupler makes it easier to use forks, buckets, etc., from wheel loaders and other machines compatible with Fusion.
Ease of use
The driver can choose controls through manipulators or with two levers, depending on their preferences or the application. Speed and direction can be controlled via a manipulator or through a V lever and pedals. The new cabin ensures driver comfort, notably thanks to a suspension seat, adjustable controls and armrests, as well as an improved air conditioning system. Excellent visibility on the bucket and all around the machine enhances safety and helps drivers work with confidence. Handles and steps allow the driver to easily enter and exit the cabin, from the front or rear of the tracks. The equipment's response can be set to different settings (fine, normal or rough), depending on the driver's preferences or the application. Emission reduction technology designed for regeneration to work automatically in the background throughout the work.
Reduced Maintenance Time
The integrated diagnostics provide drivers with onboard pressure values for faster maintenance. The tilting cab and convenient access points make maintenance and repairs easier. The variable speed fan provides efficient cooling, and the foldable panel facilitates access for maintenance. Remote monitoring via Product Link™/VisionLink® helps you manage your fleet more efficiently and cost-effectively.
Keep Things in Order
The machines specially designed for ship holds offer you the optimal combination of grip, great reach, and balance, making them ideal machines for ship hold and port handling applications. Special equipment such as coal buckets and roughing blades allow you to sweep along walls and handle a wide variety of materials. The Fusion quick attachment option offers increased versatility by facilitating the use of forks, buckets, and other equipment on compatible machines. Special joints, protections, and bumpers help protect key components. The front and rear eyelets are widely spaced for better stability during lifting. Additional spotlight sets allow for illuminating the work area.
Contact Our Experts
Morocco
International
Monday to Friday 8am-5:30pm (UTC)
Product Specifications for 963K
- ENGINE
- Net Power144 kW
- Engine ModelC7.1 Cat
- Net Power, ISO 9249/SAE J1349144 kW
- Net Power - ISO 9249/SAE J1349 (DIN)196 HP
- EmissionsU.S. EPA Tier 4 Final/European Stage IV, China Stage III standard for non-road engines, equivalent to Tier 3/Stage IIIA
- Note (1)All diesel engines that comply with Tier 4 Interim and Final, Stage IIIB and IV standards, and the Korean Tier 4 Final standard, must use only ultra-low sulfur diesel (ULSD) with a maximum 15 ppm (mg/kg) sulfur content, or up to B20 biodiesel blended with ULSD. B20 must meet ASTM D7467 specifications (biodiesel blend stock must meet Cat biodiesel specifications, or ASTM D6751 or EN 14214 standards). Cat DEO-ULS™ oils or oils that meet Cat ECF-3, API CJ-4, and ACEA E9 specifications are required. Refer to your Operation and Maintenance Manual for machine specific fuel recommendations.
- Note (2)Diesel Exhaust Fluid (DEF) used in Cat Selective Catalytic Reduction (SCR) systems must meet the requirements outlined in the International Organization for Standardization ISO 22241 standard.
- WEIGHT
- Operating Weight20021 kg
- Operating Weight (1)20308 kg
- Note(1) Machine equipped with emissions reduction technology compliant with Tier 4 Final/Stage IV standards.
- MAINTENANCE CAPACITIES
- Fuel Tank320 l
- CAPACITIES
- DEF Tank (1)16 l
- Note(1) Machine equipped with emissions reduction technology compliant with Tier 4 Final/Stage IV standards.
- DIMENSIONS
- Overall Machine Length*7001 mm
- Machine Height - Cab Top3325 mm
- Height - Top of Exhaust Pipe2940 mm
- Overall Machine Height - Fully Raised Bucket5402 mm
- Overall Machine Width without Bucket: With Standard Track: 550mm (21.6in) Shoes2400 mm
- Note*With General Purpose (GP) bucket and extra-duty teeth.
- UNDERCARRIAGE
- Track Gauge1850 mm
- Standard Track Shoe Width550 mm
- Optional Track Shoe Width450 mm
- Chain Length on Ground2542 mm
- Ground Contact Area - Standard Shoe3.2 m²
- Ground Contact Area - Optional Shoe2.6 m²
- Ground Pressure (1) - Standard Shoe62.9 kPa
- Ground Pressure (1) - Optional Shoe76.9 kPa
- Ground Pressure - Standard Shoe62 kPa
- Ground Pressure - Optional Shoe75.8 kPa
- Note(1) Machine equipped with emissions reduction technology compliant with Tier 4 Final/Stage IV standards.
- BUCKETS
- Capacity - General Purpose (GP)2.5 m³
- Capacity - Heavy Duty (All-purpose)2 m³
- Capacity - Performance Series2.8 m³
- Width - General Purpose (GP)2612 mm
- Width - Heavy Duty (All-purpose)2575 mm
- Width - Performance Series2712 mm
- AIR CONDITIONING SYSTEM
- Air ConditioningThe air conditioning system in this machine contains fluorinated greenhouse gas R134a (global warming potential = 1430). The system contains 1.1 kg of refrigerant, with a CO2 equivalent of 1.573 metric tonnes.
Standard Equipment for 963K
-
POWERTRAIN
- C7.1 Cat Diesel Engine, Turbocharged and Aftercooled (ATAAC)
- Modular Cooling System for Engine, Oil, and Water
- Radiator Fan, Electronic Control, Hydraulic Drive, Temperature Sensor, Variable Speed
- Electronic Hydrostatic Control (EHC) for Transmission with Travel and Work Modes
- Engine Idle Shutdown
- Automatic Engine Speed Control
- Electric Fuel Priming Pump
- Water Separator
- Dry-Type Axial Sealed Air Cleaner with Integrated Precleaner and Dust Ejector, Electronic Clogging Indicator
- Cold Start Aid, Glow Plug
- Cat Long-Life Coolant
-
UNDERCARRIAGE
- Cat Heavy-Duty Undercarriage: 963K (38 sections), 1,850mm (72.8 in) Track Gauge
- Track Chain Guard, End Section
- Hydraulic Track Adjuster
- Segmented Sprockets with Replaceable Bolt-On Tough Steel Segments
- Sprocket Guards
- Seven Bottom Rollers per Side, with Two Top Carrier Rollers, Lubricated for Life
- Classic Bottom Rollers, Lubricated for Life
- Oscillating Track Frame
-
ELECTRICAL SYSTEM
- Alternator, 24V, Heavy-Duty Brushless
- Reverse Warning
- Electric Horn
- Two Heavy-Duty High-Capacity Maintenance-Free Batteries: 1,120 CCA
- Battery Disconnect Switch
- Electric Starter, Heavy-Duty (24V)
-
OPERATOR'S STATION
- Sound-Reduced and Pressurized ROPS/FOPS Cabin, Tinted Glass, Sliding Right Side Window
- Air Conditioning and Heating
- Heater/Defroster with Automatic Temperature Control
- Fabric-Covered Seat, Adjustable Air Suspension
- Adjustable Armrests
- Seat-Mounted Electrohydraulic Joystick Controls with Faster Processing
- Retractable Seat Belt with Dashboard Indicator
- Electronic Monitoring System with Indicators for Engine Coolant Temperature, Hydraulic Oil Temperature, Fuel Level, Engine Oil Pressure, Diesel Exhaust Fluid Level (if applicable)
- Engine Speed and Gear Display
- Electronic Maintenance Monitor
- Rotary Throttle Dial with Economy Mode
- Center Brake Pedal
- Independent Forward/Reverse Speed Ranges Adjustments
- Electronic Transmission Speed Limiter
- Adjustable Interior Rearview Mirror
- Radio Preparation Package with 24V-to-12V Converter, Speakers, Antenna, and 12V Power Outlet
- Clothes Hook
- Storage Compartments under Left Armrest
- Document Pocket in Right Console
- Rubber Floor Mat, Heavy-Duty
- Washers and Wipers, Multiple Speeds Front and Rear
- Heavy-Duty Metal Roof
- Parking Brake Switch and Indicator
- Mudguards
-
ADDITIONAL STANDARD EQUIPMENT
- External Sound Suppression
- Z-Bar Linkage
- Variable Displacement Pump and Load Sensing
- Equipment Cylinders with Sensors
- Driver-Programmable Lift and Tilt Kickouts
- Lockable Engine Hood with Lockable Side Panels
- 6.5 FPI Radiator Spacing, Debris Resistant
- Hinged Radiator Guard and Reversible Fan
- Full Length Belly Pan Guards
- Environmentally Friendly Engine Oil Drain Valves
- Product Link Ready
- Engine Oil Sampling Ports
- Cat XT Hose
- HYDO Advanced 10
Available Options for 963K
-
POWERTRAIN
- C7.1 Cat Diesel Engine with Dual Turbochargers and Emissions Aftertreatment System compliant with US EPA Tier 4 Final/European Stage IV/Korean Tier 4 Final emissions standards OR C7.1 Cat Diesel Engine compliant with Chinese Stage III non-road engines, Indian Bharat III, European Stage IIIA, UN/ECE R96 Stage IIIA emissions standards, equivalent to Tier 3/Stage IIIA
- Variable-Speed Fan with Reverse Rotation
- Centrifugal Pre-Cleaner, Air Intake
- Transmission Control, V-shaped Lever or Joystick
-
DRIVER'S COMPARTMENT
- Standard Cab equipped with Four Halogen Headlights (Two Roof-Mounted Front-Facing, Two Integrated with Air Conditioning Unit Rear-Facing)
- Seat, Fabric Upholstery, Air Suspension, Full-Width Isolator
- Seat, Fabric Upholstery, Air Suspension, Heated, Full-Width Isolator
- Radio, AM/FM/AUX/USB/Bluetooth
- Easy Access Package (Handles and Steps)
- Cab Air Pre-Cleaner
- Additional Light Guards for Headlights
- Windshield Guard
-
HYDRAULIC SYSTEM
- Biodegradable Hydraulic Oil
- Hydraulic Groups - Standard GP: Two-Valve Joystick, Three-Valve Joystick, Two-Lever Two-Valve, Two-Lever Three-Valve
- Hydraulic Groups - All-Purpose: Three-Valve Joystick, Four-Valve Joystick
-
FUEL SYSTEM
- Quick Fuel Tank Filling
- Fuel Tank Refueling Pump
-
UNDERCARRIAGE
- Free Wheel Protection
- Free Wheel Protection with Ship Blocking
- Two-Part Gear Protection
- Three-Part Gear Protection
- Full-Length Bottom Roller Protection
- Track Groups (38 Sections) - Heavy-Duty Complete Chains: 430mm, Triple-Grouser, Sealed
- Track Groups (38 Sections) - Heavy-Duty Complete Chains: 450mm, Double-Grouser, Narrow
- Track Groups (38 Sections) - Heavy-Duty Complete Chains: 450mm, Double-Grouser, Center Notched
- Track Groups (38 Sections) - Heavy-Duty Complete Chains: 460mm, Single-Grouser, Center Notched, Greased and Sealed
- Track Groups (38 Sections) - Heavy-Duty Complete Chains: 550mm, Double-Grouser
- Track Groups (38 Sections) - Heavy-Duty Complete Chains: 550mm, Double-Grouser, Center Notched
- Track Groups (38 Sections) - Heavy-Duty Complete Chains: 560mm Single-Grouser, Heavy Duty
- Track Groups (38 Sections) - Heavy-Duty Complete Chains: 800mm, Double-Grouser
-
BUCKETS
- General Purpose (GP): 2.3 m³, Straight Edge
- General Purpose (GP): 2.5 m³
- General Purpose (GP): 2.5 m³, Full Spill Guard
- General Purpose (GP): 2.5 m³, Heavy-Duty
- General Purpose (GP): 2.8 m³, High Performance Series
- Multi-Purpose: 2.0 m³
- Multi-Purpose: 2.0 m³, Heavy-Duty
- Multi-Purpose: 2.7 m³, Sanitary Dump, Heavy-Duty
- Wide: 2.8 m³
- Sanitary Dump: 3.1 m³, Heavy-Duty
-
STARTERS, BATTERIES, AND ALTERNATORS
- Engine Coolant Heater, 120V
- Engine Coolant Heater, 240V
- Cold Weather Starting Kit, 120V: Two 12V Batteries (1,400 CCA), 120V Engine Coolant Heater, Ether Starting Aid*
- Cold Weather Starting Kit, 240V: Two 12V Batteries (1,400 CCA), 240V Engine Coolant Heater, Ether Starting Aid*
- -50°C Antifreeze
-
OTHER EQUIPMENT
- Light Counterweight, 325 kg
- Additional Counterweight, 305 kg
- Multi-Shank Ripper
- Ripper Hitch
- Rear Mud Scrapers
- Additional Work Tools: Fusion Quick Coupler, Blades, Forks, Handling Arms, Rakes
-
PROTECTIONS
- Lift Cylinder Guards
- Tilt Cylinder Guards
-
ELECTRICAL SYSTEM
- Beacon Light
-
MAINTENANCE AND OTHER EQUIPMENT
- Fuel Tank Sediment Pump
- Quick Oil Drain
- Extended Service Package: Manual Hydraulic Circuit for Safely Tilting and Locking Cab at 30 Degrees on Field, Sealed Windshield, Backhoe (backhoe not included)
-
TECHNOLOGY PRODUCTS
- Product Link - Satellite
- Product Link - Cellular
- Grade Control, Mast Receiver
-
SPECIAL EDITIONS
- Waste Handling Package, Heavy-Duty
- Waste Handling Package, Heavy-Duty, Optimized Cleaning
- Ship Blocking Package, Heavy-Duty
- Steel Mill Package, Heavy-Duty
- Low Ground Pressure Package, Heavy-Duty
- *Tier 4 Final/Stage IV Machines Only
